163
Maintenance
Toe Alignment
4. Tie an elastic string around the stands, making
sure the string just touches the side surface of
the rear tires on each side of the vehicle and
goes around the stands in front of the vehicle.
5. Measure the distance between the string in
front of the rear tires (1) and in front of the
front tires (2). If the two measurements are not
equal, adjust the string position until the mea-
surements are equal.
6. Measure the distance from the string to the rim
at the front (3) and rear (4) of the front rim.
The difference between these two measure-
ments should be between 0" and 1/16" (0-1.5
mm) toe out.
NOTE: If you discover improper alignment, see your
Polaris dealer for service.
4
Stands
String
1
2
3
