Installing the
Mounting Bracket
1. Remove the backing of the adhesive strip on the back of the
Mounting Bracket.
2. Insert the bottom of the Mounting Bracket into the track of the Bottom
Rail on the hinge side of the door.
3. Push the Mounting Bracket upwards, ensuring that the top of the Corner
Cover is tight against the upper portion of the door frame.
4. Using a level, ensure that the Mounting Bracket is positioned plumb.
Then press the Mounting Bracket firmly against the door frame, allowing
the adhesive tape to temporarily hold it in place.
5. Move the Sliding Bar and Mesh off to the side as indicated in
the illustration.
6. Using the provided screws, secure the Mounting Bracket to the
door frame.
7. Return the Sliding Bar and Mesh back to its original position, in front of
the Mounting Bracket.
9
Door Frame
(Top)
Sliding Bar
Mounting Bracket
Door Frame
