A APPPPEEN ND DIIX X D D
P PA AT TT TO ON N E EL LE EC CT TR RO ON NIIC CS S M MO OD DE EL L 1 10 08 89 9
T TR RA AN NS SM MIIS SS SIIO ON N D DIIS ST TA AN NC CE ES S
Copyright ©1999
Patton Electronics Company
All Rights Reserved
21 22
Line Rate DTE Rates
kbps feet miles km feet miles km
144 64, 128 20700 3.9 6.2 24500 4.6 7.3
272 192, 256 17400 3.3 5.2 24200 4.5 7.2
400 320, 384 15100 2.9 4.6 22600 4.2 6.7
528 448, 512 14900 2.8 4.4 21000 3.9 6.2
784 576, 640, 704, 768 13500 2.6 4.2 18000 3.4 5.4
1040 832, 896, 960, 1024 11900 2.3 3.6 15500 2.9 4.6
1168 1088 - 1152 11000 2.1 3.3 15200 2.8 4.4
Line Rate DTE Rates
kbps feet miles km feet miles km
144 64, 128 18600 3.5 5.6 22100 4.2 6.7
272 192, 256 15700 2.9 4.6 21800 4.1 6.5
400 320, 384 12800 2.4 3.8 19200 3.6 5.7
528 448, 512 13000 2.5 4 18300 3.4 5.4
784 576, 640, 704, 768 12200 2.3 3.6 16200 3.1 4.9
1040 832, 896, 960, 1024 10500 1.9 3 13600 2.5 4
1168 1088 - 1152 94000 1.7 2.7 12900 2.4 3.8
No Cross Talk
Transmission Distance - Patton NetLink HDSL Model 1089
Cross Talk (49 adjacent CAP pairs)
26 AWG (0.4mm) 24 AWG (0.5mm)
26 AWG (0.4mm) 24 AWG (0.5mm)
