Weights and dimensions shown are approximate. Specifications are subjemt to cahange without notice. This product

may be subject to export regulations. UHM is trademark of Matsushita Electric Indusutrial Co., Ltd. VGA and

XGA are trademarks of International Business Machines Corporation. All other trademarks are the property of their

respective trademark owners. Projection Images simulated.

DLP, DLP logo and DLP Medallion logo are trademarks of Texas Instruments.

PT-DW5000E2-06Jul30K Printed in Japan.

Please contact Panasonic or your dealer for a demonstration.

JQA-1617

Projection distance

Optional accessories

Specifications

Dimensions

System
Device
Pixels
Lamp
Brightness (normal lamp)
Brightness (long life lamp)
Contrast ratio
Resolution

RGB
Video

Lens

PT-DW5000E

PT-DW5000EL

Screen size
Lens shift
RGB input scanning

frequency

Component signal
Video signal

Terminals

VIDEO IN
S-VIDEO IN
RGB1/YP

RGB2 IN
DVI-D IN
RS-232C IN
RS-232C OUT
REMOTE 1 IN
REMOTE 1 OUT
REMOTE 2 IN
LAN

Keystone correction range
Installation
Power cord length
Power supply
Power consumption
Dimensions (W x H x D)
Weight

PT-DW5000E
PT-DW5000EL

Operating temperature
Operating humidity
Supplied accessories

DLP

™

system

0.65" (diagonal) DLP

™

(x 1), 15:9

983,040 (1,280 x 768) x 1
300 W UHM

lamp x 2 (Dual Lamp System)

4,500 lumens (dual lamp, high power mode)
2,250 lumens (dual lamp)
2,000:1 (full on/full off, contrast mode: high)

1,280 x 768 pixels
560 TV lines

Powered zoom/focus lens (1:1.8-1:2.5)
F 1.7-2.0, f 25.6-33.8 mm
Optional powered zoom/focus lenses
50 - 600 inches
Vertical, horizontal

15-91 kHz, f

50-85 Hz

Dot clock 108 MHz or lower
480i, 480p, 576i, 576p, 720/60p, 720/50p, 1035/60i, 1080/60i, 1080/50i
NTSC, PAL, SECAM, NTSC4.43, PAL60, PAL-M, PAL-N

BNC
Mini DIN 4-pin
BNC x 5
D-sub HD 15-pin
24 pin
D-sub 9-pin female
D-sub 9-pin male
M3 jack
M3 jack
D-sub 9-pin female (parallel)
RJ-45 (10 Base-T/100 Base-TX)

30˚ (with standard lens)

Front/rear, ceiling/floor
3.0m (9.9')
220-240 V AC, 50/60 Hz
750 W (790 VA) (15 W during standby mode with fan stopped)
530 x 167 x 429 mm (20-7/8' x 6-9/16' x 16-7/8') (without lens)

14.5 kg (32.0 lbs) with supplied lens
13.7 kg (30.2 lbs) without lens
32 -113 F (0 -45 C)
20-80% (no condensation)
Power cord, Wireless/wired remote control unit,
Batteries for remote control (x 2)

Normal Lamp Replacement Unit
ET-LAD55
ET-LAD55W (twin pack)

Long Life Lamp Replacement Unit
ET-LAD55L
ET-LAD55LW (twin pack)

Zoom Lens (1.3-1.8:1):ET-DLE100
Zoom Lens (2.5-4.0:1):ET-DLE200
Zoom Lens (3.4-4.5:1):ET-DLE310
Zoom Lens (4.5-8.4:1):ET-DLE410
Fixed Focus Lens (0.8:1):ET-DLE050

NOTES ON USE

Notes on Projector Placement and Operation:
The projector uses a high-wattage lamp that becomes very hot during operation. Please
observe the following precautions.

1. Never place objects on top of the projector while it is operating.
2. Make sure there is an unobstructed space of 500 mm or more around the projector's
exhaust openings.
3. Do not stack projector units directly on top of one another for the purpose of multiple (stacked)
projection. When stacking projector units, be sure to provide the amount of space indicated
below between them. These space requirements also apply to installations where only one
projector unit is operating at one time and the other unit is used as a backup.
4. If the projector is placed in a box or enclosure, ensure the temperature of the air surrounding
the projector is between 0˚C and 35˚C. Also make sure the projector's intake and exhaust
openings are not blocked. Take particular care to ensure that hot air from the exhaust
openings is not sucked into the intake openings.

Operating the Projector Continuously:
1. If the projector is to be operated continuously 24 hours a day, use the dual-lamp optical
system's alternating lamp operation (lamp changer) function. The projector cannot be
operated continuously 24 hours a day in dual-lamp mode. Allow a minimum of two hours
per day of non-operation time per day if the using the dual-lamp mode.
2. The lamp replacement cycle duration becomes shorter if the projector is operated
repeatedly for short periods.

• The projector uses a high-voltage mercury lamp that contains high internal pressure.
This lamp may break, emitting a large sound, or fail to illuminate, due to impact or
extended use. The length of time that it takes for the lamp to break or fail to illuminate
varies greatly depending on individual lamp characteristics and usage conditions.
• The brightness of the lamp will gradually decrease with use.

unit: mm [inch]

Low-Ceiling Mount Bracket
ET-PKD55S

Wireless Mouse Receiver
ET-RMRC2

Ceiling Mount Bracket
ET-PKD56H

Throw distance

Screen size (16:9)

With ET-DLE050

0.8:1

50"(4.2')

1.3 m

80"(6.7')

2.0 m

100"(8.3')

2.5 m

150"(12.5')

3.8 m

200"(16.7')

5.1 m

300"(25.0')

7.6 m

400"(33.3')

1.3 m

500"(41.7')

12.7 m

600"(50.0')

15.2 m

2.88'

0.88m

4.68'

1.43m

5.88'

1.79m

8.89'

2.71m

11.89'
3.62m

-
-

With ET-DLE100

1.3-1.8:1

min.

4.85'

1.48m

7.85'

2.39m

9.86'

3.00m

14.86'
4.53m

19.86'
6.05m

29.86'
9.10m

39.87'

12.15m

49.87'

15.20m

59.88'

18.25m

max.

6.58'

2.01m

10.63'
3.24m

13.32'
4.06m

20.06'
6.12m

26.80'
8.17m

40.29'

12.28m

53.77'

16.39m

67.25'

20.50m

80.73'

24.61m

With supplied lens

1.8-2.5:1

min.

6.49'

1.98m

10.52'
3.21m

13.20'
4.03m

19.91'
6.07m

26.62'
8.12m

40.03'

12.21m

53.45'

16.30m

66.86'

20.39m

80.28'

24.48m

max.

8.63'

2.63m

13.93'
4.25m

17.47'
5.33m

26.31'
8.02m

35.15'

10.72m

52.83'

16.11m

70.51'

21.50m

88.19'

26.89m

105.87'
32.28m

With ET-DLE200

2.5-4.0:1

min.

8.90'

2.71m

14.37'
4.38m

18.02'
5.49m

27.14'
8.27m

36.26'

11.05m

54.49'

16.61m

72.73'

22.17m

90.97'

27.73m

109.21'
33.29m

max.

14.68'
4.47m

23.63'
7.20m

29.60'
9.02m

44.52'

13.57m

59.45'

18.12m

89.30'

27.22m

119.14'
36.32m

148.99'
45.42m

178.84'
54.52m

With ET-DLE410

4.5-8.4:1

min.

16.95'
5.17m

27.39'
8.35m

34.35'

10.47m

51.75'

15.78m

69.15'

21.08m

103.95'
31.69m

138.75'
42.30m

173.55'
52.91m

208.35'
63.52m

max.

32.08'
9.78m

51.59'

15.73m

64.6'

19.69m

97.12'

29.61m

129.64'
39.52m

194.68'
59.35m

259.73'
79.18m

324.77'
99.01m

389.81'

118.84m

With ET-DLE310

3.4-4.5:1

min.

12.76'
3.89m

20.62'
6.29m

25.86'
7.88m

38.96'

11.88m

52.07'

15.87m

78.27'

23.86m

104.48'
31.85m

130.69'
39.84m

156.89'
47.83m

max.

16.76'
5.11m

27.02'
8.24m

33.86'

10.32m

50.97'

15.54m

68.07'

20.75m

102.28'
31.18m

136.50'
41.61m

170.71'
52.04m

204.92'
62.47m

>PC<

TBMU448

RGB 2 IN

SYNC/HD

B/PB

G/Y

R/P

SERIAL

REMOTE 1

REMOTE 2

OUT

LAN

DVI-D IN

RGB 1 IN

VIDEO IN

S-VIDEO IN

OUT

530 (20 7/8)

167 (6 9/16)

429 (16 7/8)

gray

White

Black

Colour
saturation

gray

Brightness
