Operating this unit
3. Push MULTI-CONTROL left or right to select cut-off frequency.
Each time MULTI-CONTROL is pushed left or right, cut-off frequencies are selected
in the following order:
50Hz – 63Hz – 80Hz – 100Hz – 125Hz
Only frequencies higher than those in the selected range are outputted from the front
or rear speakers.
Adjusting source levels
SLA (source level adjustment) lets you adjust the volume level of each source to
prevent radical changes in volume when switching between sources.
• Settings are based on the FM tuner volume level, which remains unchanged.
1. Compare the FM tuner volume level with the level of the source you wish to
adjust.
2. Use MULTI-CONTROL to select SLA.
3. Push MULTI-CONTROL up or down to adjust the source volume.
Each time MULTI-CONTROL is pushed up or down, source volume increases or
decreases.
SLA +4 to SLA –4 is displayed as the source volume is increased or decreased.
Notes
• The MW/LW tuner volume level can also be adjusted with source level adjustments.
• The built-in CD player and the multi-CD player are set to the same source level adjustment
volume automatically.
• External unit 1 and external unit 2 are set to the same source level adjustment volume
automatically.
Using automatic sound levelizer
During driving, noise in the car changes according to the driving speed and road
conditions. The automatic sound levelizer (ASL) monitors such varying noise and
automatically increases the volume level, if this noise becomes greater. The sensitivity
(variation of volume level to noise level) of ASL can be set to one of five levels.
1. Use MULTI-CONTROL to select ASL.
2. Press MULTI-CONTROL to turn ASL on.
Mid appears in the display.
• To turn ASL off, press MULTI-CONTROL again.
3. Push MULTI-CONTROL left or right to select the desired ASL level.
Each time MULTI-CONTROL is pushed left or right, ASL level is selected in the
following order:
Low (low) – Mid-L (mid-low) – Mid (mid) – Mid-H (mid-high) – High (high)
Initial Settings
Adjusting initial settings
Using the initial settings, you can customize various system settings to achieve optimal
performance from this unit.
1. Press SOURCE and hold until the unit
turns off.
2. Press MULTI-CONTROL and hold until
Language select appears in the
display.
3. Turn MULTI-CONTROL to select one of the initial settings.
Turn MULTI-CONTROL to switch between the functions in the following order:
Language select (language selection) – Clock (clock) – Off clock (off clock) – FM
step (FM tuning step) – Auto PI (auto PI seek) – Warning tone (warning tone) – Face
auto open (face auto open) – AUX1 (auxiliary input 1) – AUX2 (auxiliary input 2) –
Dimmer (dimmer) – Brightness (brightness) – S/W control (rear output and
subwoofer controller) – Mute (sound muting/attenuation) – Demonstration (feature
demo) – Reverse mode (reverse mode) – Ever-scroll (ever scroll) – BT AUDIO
(Bluetooth audio) – Pin code input (pin code input)
Use the following instructions to operate each particular setting.
• You can also select the function by pressing FUNCTION on the remote control.
• BT AUDIO and Pin code input can be selected only when Bluetooth adapter (e.g.,
CD-BTB100) is connected to this unit.
• To cancel initial settings, press BAND.
Selecting the display language
For your convenience, this unit equips multiple language display. You can select the
language best suited to your first language.
1. Use MULTI-CONTROL to select Language select.
2. Press MULTI-CONTROL to select the language.
Each press of MULTI-CONTROL selects languages in the following order:
English – Français – Italiano – Español – Deutsch – Nederlands – РУССКИЙ
ቢ Function display
Shows the function status.
