Checking the Supplied Accessories
Remove the main unit and the accessories from the box and check that the following items are included.
“WARNING”
Handling the cables supplied with this product, will ex-
pose you to lead, a chemical known to the State of Cali-
fornia to cause birth defects or other reproductive harm.
Wash hands after handling.
RGB signal cable
(Mini D-sub 15-pin, 2 m / 6.6 feet) [1]
This is used in making connections with a personal computer.
See Page E-16 about connections.
No. M01800500 Wireless remote control unit (with wireless LAN)
(includes one button battery) [1]
Applicable Projector: KG-PS125X
This controls the projector. Please remove the transportation
insulation sheet at time of purchase. (See Page E-13.)
COMPUTER
PO WE R/
ST AN DB Y
QU ICK CO LO R AD
J
VIDEO
FREEZE
MUTE
ECO
WIRE
LE SS VIEWER
VOL
KSTN
ZOOM
CANCEL
QUICK
MENU ENTER
Q
Wireless remote control unit (without wireless LAN)
(includes one button battery) [1]
Applicable Projector: KG-PS100S/KG-PS120X
This controls the projector. Please remove the transportation
insulation sheet at time of purchase. (See Page E-13.)
COMPUTER
PO WE R/
ST AN DB Y
QU ICK CO LO R A DJ
VIDEO
FREEZE
MUTE
ECO
ASPECT
AUTO
VOL
KSTN
ZOOM
CANCEL
QUICK
MENU ENTER
Q
Audio conversion adapter (Mini plug / RCA pin plug, 15 cm
/ 0.5 feet) [1]
This cable is used with equipment whose audio connector is
of the phono pin type. Connections are described on Page
E-20.
No. M01800600
Power cable (1.8 m / 5.9 feet) [1]
This power cable supplies power to the unit. See Page E-21
about connections. SD wireless LAN card [1]
Applicable Projector: KG-PS125X
Ferrite cores [3]
These ferrite cores are attached to power cable, video cable
and S-video cable.
Mounting
→ See Pages E-18, 21.
