background image

Ref.No.

Part No.

Part Name & DescriptionPcs

Remarks

Ref.No.

Part No.

Part Name & DescriptionPcs

Remarks

1

VXQ1457

PRISM U

1

2

VGQ9068

CCD HEAT SINK SHEET

1

3

VXW0892

LENS U

1

3-1

L6HA66NC0010 ZOOM MOTOR

1

3-2

VXP2687

IRISI U

1

3-3

VMA0S74

SIDE YORK

2

3-4

VMS7778

Z GUIDE POLE

2

3-5

VEK0K40

LENS FPC U

1

3-6

VMS7779

F GUIDE POLE

1

3-7

VXP2667

2ND LENS FRAME MOVE

1

3-8

VXP2670

4TH LENS FRAME MOVE

1

3-9

VXQ1524

OIS U

1

3-10

VXQ1456

MASTER FLENGE U

1

3-11

VDW1342

MAIN FRAME

1

3-12

VXQ1452

1ST LENS FRAME MOVE

1

3-13

VMB4079

2ND LENS SPRING

1

4

VDL1900

CRYSTAL OPTICAL FILTER

1

101

XQN16+CJ4FJR SCREW

10

102

XQN16+CJ7FJ

SCREW

3

103

XQN16+CJ5FJ

SCREW

2

E23

VEP22374A

CCD FPC C.B.A.

1

LENS PARTS ASSEMBLY

MPL-6
