Battery / rear jack parts assembly, Mpl-14 – Panasonic AG-HMC70P User Manual
Page 15
Ref.No.
Part No.
Part Name & DescriptionPcs
Remarks
Ref.No.
Part No.
Part Name & DescriptionPcs
Remarks
1
VMP9055
BATTERY HOLD FRAME
1
2
VMP9057
REAR JACK FRAME
1
3
VGU9300
SLIDE SW BUTTON
4
4
VGH4984
SLIDE SW SHEET
4
5
VMT1884
SLIDE SW SPONGE
4
6
VGQ9916
SHEET
1
7
VGH5038
REAR JACK SHEET
1
8
VWJ2054
OP CN XLR JACK FFC
1
9
VWJ1784
10P0505061 FPC
1
10
VGP6231
REAR JACK CASE
1
11
VGU0C35
BATTERY LOCK BUTTON
1
12
VGQ9771
BATTERY LOCK
1
13
VMB4171
BATTERY BT SPRING
2
14
VMP9056
BATTERY LOCK FRAME
1
15
VGQ9772
BATTERY BASE
1
16
VGQ9842
BATTERY LOCK BACK
1
17
VMG1833
JACK COVER REAR
1
18
VMG1832
JACK COVER L
1
19
VQL1T01
FCC/DOC LABEL
1 FOR AG-HMC70P
101
XQN2+B6FJK
SCREW
13
102
XSN26+8FJK
SCREW
4
103
XQN2+BJ6FN
SCREW
6
104
VMX3574
SPACER
2
105
XTB3+10GFJK
SCREW
1
106
VHN0382
M6 NUT
1
107
XTV3+8GFN
SCREW
2
108
VHD1774
SCREW
2
E10
VEP01A04A
DC JACK C.B.A.
1
E11
VEP04933A
HP JACK C.B.A.
1
E12
VEP04931A
XLR JACK C.B.A.
1
E13
VEP04934A
XLR SUB C.B.A.
1
E21
VEP01A05A
BATTERY C.B.A.
1
BATTERY / REAR JACK PARTS ASSEMBLY
MPL-14
