Page 11
Ref.No.
Part No.
Part Name & DescriptionPcs
Remarks
Ref.No.
Part No.
Part Name & DescriptionPcs
Remarks
1
VGP6103
EVF HOLD CASE
1
2
VGM2110
EVF SLIDE FRAME
1
3
VGP6104
EVF CABLE HOLD COVER
1
4
VDL2106
EVF FILTER
1
5
VGQ9773
DIOPTER HOLE COVER
1
6
VJF0804
LENS CABLE CLAMPER
1
7
VGP6101
EVF SLIDE CASE TOP
1
8
VGP6102
EVF SLIDE CASE BOTTOM
1
9
VMC1949
PLATE SPRING
2
10
VGP6100
EVF ROTATE CASE BOTTOM
1
11
VYK2P74
EVF DIOPTER UNIT
1
12
VKF4309
EVF COVER
1
13
VYK2P14
EVF LCD U
1
14
VGQ9122
SLIDE HOLDER
1
15
VGQ9123
EVF PROTECT PIECE
1
16
VMP8712
EVF FRAME
1
17
VGQ9196
SLIDE SPACER
2
18
VWJ2024
EVF FPC
1
19
VMP9093
EVF COVER PLATE
1
20
VGQ6407
TAPE
1
21
VGP6099
EVF ROTATE CASE TOP
1
22
VMG1665
EVF LOCK PACKING (O RING)
1
23
VMX3446
EVF RING
1
24
VMP8195
EVF RELAY PB HOLD PLATE
1
25
VMZ3552
EVF FPC GUIDE SHEET
1
26
VJF1559
PAN TIES PLT.7M
1
27
VEE1E54
EVF CABLE
1
28
J0KG00000036 FILTER FOR EMI / EMC (CORES 1
29
VGQ8248
EVF SLIDE STOPPER PLATE
1
101
XQN2+BJ6FJK
SCREW
11
102
XTS2+8AFJK
SCREW
4
103
VHD1822
SCREW
2
104
XQN16+BJ4FN
SCREW
4
105
XQN2+B2FN
SCREW
2
106
VHD1775
SCREW
1
107
XYN2+J4FJ
SCREW
2
108
XQN2+B6FJK
SCREW
2
109
XTB3+10GFJK
SCREW
7
110
XQN2+BJ4FJK
SCREW
2
E19
VEP29201A
EVF BL C.B.A.
1
E20
VEP29202A
EVF INTER CN C.B.A.
1
EVF PARTS ASSEMBLY
MPL-10
