Ref.No.

Part No.

Part Name & DescriptionPcs

Remarks

Ref.No.

Part No.

Part Name & DescriptionPcs

Remarks

1

N9ZZ00000390 OPERATION SW U

1

2

VMP9063

GRIP PB FRAME

1

3

VMP9095

GRIP PLATE

1

4

VMP9101

GRIP PLATE B

1

5

VSC6050

GRIP SHIELD PLATE

1

6

VGP6225

GRIP CASE

1

7

VGQ9873

GRIP COVER

1

8

VYK2P42

GRIP ZOOM U

1

9

VWJ1924

FRONT FPC

1

10

VWJ2046

GRIP CN ZOOM FFC

1

11

VKW3383

IR WINDOW

1

12

VJF0804

LENS CABLE CLAMPER

1

13

VGQ9770

ZOOM U BASE

1

14

VFC4298

GRIP BELT

1

101

XTB26+6GFJ

SCREW

11

102

XQN16+BJ4FN

SCREW

4

103

XYN2+J4FJ

SCREW

4

104

XQN2+BJ5FJK

SCREW

4

105

XTB3+10GFJK

SCREW

5

E7

VEP001U7A

FRONT C.B.A.

1

E15

VEP001U9A

GRIP CN C.B.A.

1

E22

VEP001U8A

ZOOM C.B.A.

1

GRIP PARTS ASSEMBLY

MPL-12
