8 Basic Operation Instructions
Cantilever Lift System www.quantumrehab.com RevA/Nov03
VIBE WITH CANTILEVER LIFT SYSTEM SPECIFICATIONS
Suspension: Full suspension - Sport Trac
Drive Wheels: 14 in., pneumatic, rear-mounted (14 in., solid are optional)
Caster Wheels: 9 in. pneumatic, front-mounted (9 in. solid, 8 in. solid, and 6 in.
solid are optional)
Anti-tip Wheels: 4 in., solid, rear-mounted
Maximum Speed:* Up to 6 mph
Brakes: “Intelligent Braking” electronic regenerative, disc park brake
Ground Clearance: 3.75 in.
Turning Radius: 24 in. (without foot riggings)
Turning Diameter 48 in. (without foot riggings)
Overall Size: Length: 35.5 in. (without foot riggings)
Length: 48 in. (with swing-away footrests)
Width: 25 in.
Seating Options: Specialty Seat (standard)
Medium-Back Seat (optional)
Synergy Seat (optional)
High-Back Seat (optional)
Reclining Seat (optional)
Drivetrain: Two motor, rear-wheel drive
Batteries: Group 34
Range:* Up to 25 miles
Battery Charger: 8-amp, off-board
Electronics: 50-amp PG Drives VSI (standard)
70-amp PG Drives Remote Plus (optional)
70-amp Dynamic Europa (optional)
Weight Capacity: 300 lbs.
Component Weights: Base: 90.5 lbs. (without batteries and with pneumatic drive wheels)
Cantilever Lift Speed: 1/2-in. per second
Cantilever Lift
Extention: Maximum 12 in.
*Depending on user weight and terrain.
