Basic Operation Instructions 11
Cantilever Lift System www.quantumrehab.com RevA/Nov03
Figure 5. Europa Controller
CANTILEVER LIFT OPERATION - EUROPA
To operate the cantilever lift:
1. Bring your power chair to a complete stop.
2. Press an actuator select key until an “A” appears in the drive mode and actuator
display. See figure 5.
3. Pull the joystick back to raise the lift. Push the joystick forward to lower the
lift. Once the lift reaches its highest extension and the lift action stops, you
should continue to hear and/or feel the lift motor running. This is because there
is a clutch mechanism that allows the motor to continue running after the lift
has reached its limit. This clutch works at both the top and bottom extensions
of the lift. When you release the joystick, the lift motor will stop.
NOTE: Do not allow the motor to run more than a few seconds after
the mechanism reaches the top or bottom limit.
4. Press the drive program select key until a number appears in the drive mode
and actuator display.
