Planet Technology FNSW-4800v2 - Manual (Page 8)

1.4 Specification
Product
FNSW-4800v2
48-Port 10/100Mbps Fast Ethernet Switch
Hardware Specification
Ports
48 10/ 100Base-TX RJ-45 Auto-MDI/MDI-X
ports
Switch Processing
Scheme
Store-and-Forward
Throughput (packet
per second)
6.6Mpps
Switch fabric 8.8Gbps
Address Table 8K entries
Share data Buffer 2.5Mbit
Flow Control
Back pressure for half duplex, IEEE 802.3x
Pause Frame for full duplex
Dimensions
(W x D x H)
440 x 260 x 44 mm, 1U height
Weight 3.18kg
Power Requirement 100~240V AC, 50-60 Hz, 0.6A
Power Consumption
/ Dissipation
18 Watts / 61 BTU
Temperature
Operating: 0~50 degree C, Storage -40~70
degree C
Humidity
Operating: 10% to 90%, Storage: 5% to 95% (Non-
condensing)
Standards Conformance
Regulation
Compliance
FCC Part 15 Class A, CE
Standards
Compliance
IEEE 802.3 (Ethernet)
IEEE 802.3u (Fast Ethernet)
IEEE 802.3x (Flow control)
