LC640.480.33-AC Operations Manual (OM600-01) 17
Video Connector (J3)
Video signals and LCD display power (V
L
) are applied via a polarized 34-pin dual-row 2
mm pitch header with gold plated (30
µ
") contact surfaces and ejector/latching ears. The
connector is equivalent to a Samtec EHT-117-01-S-D-RA and the recommended mating
cable is a Samtec TCSD-117. Consult your Samtec representative (1-800-SAMTEC9) for
cable and connector options. Note that J3 is electrically and mechanically independent of
the backlight assembly.
Table 13. Video Connector (J3) Pinouts.
Pin Signal Description Pin Signal Description
1 GND Ground 2 CK Dot Clock
3 HSync Horiz. Sync 4 VSync Vert. Sync
5 GND Ground 6 R0 Red data (LSB)
7 R1 Red data 8 R2 Red data
9 R3 Red data 10 R4 Red data
11 R5 Red data (MSB) 12 GND Ground
13 G0 Green data (LSB) 14 G1 Green data
15 G2 Green data 16 G3 Green data
17 G4 Green data 18 G5 Green data (MSB)
19 GND Ground 20 B0 Blue data (LSB)
21 B1 Blue data 22 B2 Blue data
23 B3 Blue data 24 B4 Blue data
25 B5 Blue data (MSB) 26 GND Ground
27 ENAB 1 Enable 1 28 V
L
LCD Power
29 V
L
LCD Power 30 GND Ground
31 R/L 2 Horiz. Scan 2 32 U/D 3 Vert. Scan 3
33 GND Ground 34 GND Ground
Ground (GND) is isolated from the display metal bezel.
1 Do not keep ENAB at a static high level.
2
Default is logic high or open connection. Reverse scan direction is logic low.
3
Default is logic low or open connection. Reverse scan direction is logic high.
