Ref. No. Part No. Part Name & Description Pcs Remarks
TOP CASE ASSEMBLY
Ref. No. Part No. Part Name & Description Pcs Remarks
1 VGMB0093 TOP CASE 1
2 V5RA0281A4 ROTARY SWITCH KNOB
3 VMGB0046 RUBBER BUTTON 1
4 VGPB0090 TOP SWITCH PANEL 1
5 VMTB0134 KNOB CUSHION 1
6 VGPB0089 UNIT PANEL 1
7 VMAB0192 OPTION MOUNTING ANGLE
8 K1ZZ00000314 DUST CAP 1
9 VMG0948 EVF SEALING PACKING
10 VMAB0178 EVF CN MOUNTING ANGLE
11 VGQB0142 P.C.B. GUIDE RAIL 1
102 XQN2+A8FJK SCREW 2
103 XQN26+A6FN SCREW 2
105 XQN26+A6FJK SCREW 2
110 XSS2+4FN SCREW 2
122 XSB4+8FJK SCREW 2
127 XYN26+J5FN SCREW w/ WASHER 2
SCREW w/ WASHER XYN26+J6FJK 128 4
201 VGNB0216-2 MAIN LABEL 1 (P)
202 3PD003497AAA PRODUCT DATE LABEL
330 VEEB0267 CABLE
333 VEEB0270 CABLE
E31 S1VEPB0519A MONI SEL P.C.BOARD
PRT-6
1 (MC)
1
1
1 (RTL)
1
1
1
1
VGNB0217-1 MAIN LABEL 1 (MC)
VGNB0218-1 MAIN LABEL 1 (E)
201
201
