Ref. No. Part No. Part Name & Description Pcs Remarks
BOTTOM CASE (2) ASSEMBLY
Ref. No. Part No. Part Name & Description Pcs Remarks
1 VGMB0098 FRONT BASE 1
2 VGM1826 FRONT V EDGE 1
3 VGMB0094 BOTTOM CASE 1
4 VMGB0047 BREAKER CAP 1
5 VMP6370 BACK LOCK ANGLE 1
6 VGQB0145 SLIDE GEAR (B) 1
7 VGMB0100 COVER LOCK PROTECTOR 2
8 VMBB0020 LOCK SPRING 2
9 VMAB0191 LOCK COVER PLATE 2
10 VMPB0102 BEARING METAL 1
11 VGQB0148 PROTECT COVER 1
12 VMBB0018 PROTECT SPRING 1
13 VMSB0027 PROTECT SHAFT 1
14 VGQB0142 P.C.B. GUIDE RAIL 1
15 VMAB0180 LENS CN MOUNTING ANGLE 1
16 VMGB0053 XLR CAP(FEMALE) 1
106 XQS2+A4FJK SCREW 4
108 XSN26+6FJK SCREW 4
114 XSS3+8FJK SCREW 4
118 XSB26+6FJK SCREW 3
121 XSB4+6FN SCREW 3
127 XYN26+J5FN SCREW w/ WASHER 2
128 XYN26+J6FJK SCREW w/ WASHER 4
129 XYN3+J6FN SCREW w/ WASHER 2
335 VEEB0272-2 CABLE
E21 S1VEPB0484A FRONT MIC P.C.BOARD 1 (RTL)
PRT-10
1
