List, Rear case (2) assembly, Prt-14 – Panasonic AK-HC3500 User Manual
Page 15
Ref. No.
Part No.
Part Name & Description Pcs
Remarks
REAR CASE (2) ASSEMBLY
Ref. No.
Part No.
Part Name & Description Pcs
Remarks
1
VMD4892-1
V EDGE (FEMALE)
1
2
VMB3806
V EDGE LOCK SPRING
1
3
VMD4893-1
V EDGE LOCK
1
4
VMLB0052
LOCK RELEASE LEVER
1
5
VKF3777
V EDGE COVER
1
6
VGU9447
LOCK RELEASE KNOB
1
7
VGMB0105
D-SUB MOUNTING ANGLE
1
8
VMAB0189
D-SUB PLATE NUT
1
9
VGMB0102
OPTICAL CONNECTOR CASE
1
10
5Z1A006A
OPTICAL CN WASHER
1
11
2F1A034A
OPT CN MOUNTING ANGLE
1
12
8Z1A004A
WAVE WASHER
2
13
VMAB0187
OPTICAL CN ST
OPPER
1
14
0CB562
BUSHING
1
15
VGMB0095-1
REAR CASE
1
16
VGFB0015
FAN LOUVER
1
17
VMGB0055
SHIELD TUBE (B)
1
18
VMGB0049
BNC CAP(SDI)
1
19
VMG1491
BOTTOM GUARD
1
20
VMAB0226
STOPPER PLATE
1
21
VMGB0048
VIBLATION INSULATOR
1
22
VMAB0188
FAN MOUNTING ANGLE
1
23
VMAB0190
BNC MOUNTING ANGLE
1
24
K1SYYYYA0002 BNC CONNECTOR
3
101
XQN2+A4FJK
SCREW
7
106
XQS2+A4FJK
SCREW
4
109
XSN3+8FN
SCREW
4
111
XSS26+6FN
SCREW
3
112
XSS26+6FJK
SCREW
2
113
XSS3+6FJK
SCREW
4
116
XSB2+6FJK
SCREW
2
119
XSB3+6FJK
SCREW
2
120
XSB3+8FJK
SCREW
2
127
XYN26+J5FN
SCREW w/ WASHER
7
R
E
H
S
A
W
/
w
W
E
R
C
S
N
F
6
J
+
3
N
Y
X
9
2
1
1
201
V7MA0338A4
SEE MANUAL LABEL
1 (P)
310
VEEB0246-2
CABLE
317
VEEB0253
CABLE
317
VEEB0254
CABLE
328
VEEB0265
CABLE
305
VEEB0345
FAN ASSY
1
PRT-14
1
1 (P)
1 (E, MC)
1
