Ref. No. Part No. Part Name & Description Pcs Remarks
REAR CASE (1) ASSEMBLY
Ref. No. Part No. Part Name & Description Pcs Remarks
1 N0BM1EJ00012 DC / DC CONVERTER 1
2 VMAB0186-1 PW UNIT MOUNTING ANGLE 1
3 VMG1495 BNC CAP 2
4 VMGB0052 XLR CAP(MALE) 1
5 VGMB0104 BLANK PANEL 1
6 VMS4284 BELT HOOK SCREW 1
7 VKFB0003 D-SUB COVER 1
8 VMTB0142 D-SUB CUSHION 1
9 VGMB0106 INCOM PANEL 1
10 VGQB0150 GUARD BRACKET 1
11 VMX3255-1 GUARD MOUNTING BRACKET 2
12 VMGB0046 RUBBER BUTTON 1
13 V5RA0281A4 ROTARY SWITCH KNOB 2
14 VMTB0134 KNOB CUSHION 2
15 VMGB0062 TOGGLE SWITCH SHEET 1
16 VMTB0135 WATERPROOF SHEET 1
17 BSU2606 SPACER 2
18 VMTB0143 LED MASK 1
19 VGUB0033 VR KNOB 6
20 VGPB0091 REAR PANEL 1
21 K1ZZ00000314 DUST CAP 2
22 K1YD12000003 DUST CAP 2
23 K1ZZ00000817 DUST CAP 1
24 VMXB0062 EARPHONE SPACER 1
25 VGQ7035-1 EARPHONE CAP 1
26 3AE001046AAA NUT WASHER 1
27 VMG1085 SLIDE SW SEALING PACKING 2
28 VGUB0034 SLIDE SW KNOB 2
29 VMGB0062 TOGGLE SWITCH SHEET 3
30 VMGB0053 XLR CAP(FEMALE) 2
104 XQN26+A6FJK SCREW 16
107 XSN26+6FN SCREW 6
108 XSN26+6FJK SCREW 4
117 XSB26+6FN SCREW 2
R E H S A W / w W E R C S N F 5 J + 6 2 N Y X 7 2 1 7
R E H S A W / w W E R C S N F 6 J + 3 N Y X 9 2 1 4
201 VQLB0261 INCOM LABEL 1
306 VEEB0242 CABLE
307 VEEB0243 CABLE
309 VEEB0245 CABLE
324 VEEB0261-1 CABLE
329 VEEB0266 CABLE
338 VEEB0275-1 CABLE
318 VEEB0342-2 CABLE
319 VEEB0343-2 CABLE
E19 S1VEPB0482B INCOM P.C.BOARD 1 (RTL)
E20 S1VEPB0483B REAR SW P.C.BOARD 1 (RTL)
E22 S1VEPB0485A EARPHONE P.C.BOARD 1 (RTL)
E27 S1VEPB0495B MIC AMP P.C.BOARD 1 (RTL)
E28 S1VEPB0515B INCOM SW P.C.BOARD 1 (RTL)
E29 S1VEPB0516B INCOM LED P.C.BOARD 1 (RTL)
PRT-12
