SPECIFICATIONS

PA200.4

PA500.4

PA1100.5

Dynamic Power Rating

80W x 4

@ 2 Ohms

200W x 4

@ 2 Ohms

200W x 4 @ 2 Ohms

1200W x 1 @ 1 Ohm

RMS Continuous Power

Bridged @ 4 Ohms

100W x 2

250W x 2

600W x 1 @ 1 Ohm

RMS Continuous Power

@ 2 Ohms

50W x 4

125W x 4

600W x 1 @ 1 Ohm

RMS Continuous Power

@ 4 Ohms

35W x 4

90W x 4

80W x 4

280W x 1

Conversion Efficiency

>66% @ 4 ohms

Frequency Response

20Hz-20kHz

Signal to Noise Ratio

>90dBA

>98dBA

Separation

65db @ 1kHz

Damping Factor

>100

>150

(>50 sub channel)

Crossover Type/Range

Switchable

high or low pass

2-way Butterworth

50 to 500Hz

2-way Butterworth

50 to 500Hz

Crossover Slope

12dB/octave

Bass Equalization

+8dB, centered

@ 40Hz

0 to +8dB

Subsonic Filter

Variable

RCA Input/Output Jacks

2-channel in/2-channel

paralleled full range out

Input Impedance

20K ohms

Input Sensitivity

Variable from

250mV to 7.5V

Variable from

250mV to 8V

Variable from

250mV to 8V

Supply Voltage

10-16VDC

Fusing/Type

1 x 30A

2 x 40A

3 x 40A

Minimum Cable Required

#10

Port Output (Optional Fan)
LED(Optional)

12V @ <200mA

RMS continuous power driven into 4 Ohms from 20 to 20,000 Hz @ 14.4VDC with less than 0.08% THD+N.

RMS continuous power driven into 2 Ohms from 20 to 20,000 Hz @ 14.4VDC with less than 0.15% THD+N.

LED TUBE INSTALLATION (OPTIONAL)

These Polk Audio amplifiers have been designed with
a custom heat sink that can accommodate two
(optional—not supplied) VARAD LED tubes.

1. Before installing the LED tubes, remove and discard

the mounting feet from the VARAD LED tubes.

2. Slide each LED tube assembly into your Polk Audio

amplifier heat sink. Ensure that the LEDs are facing
out for optimal visibility. The wires from the LED tube
assembly should be on the signal input end of the
amplifier. The Black wire from the LED tube is ground
and the Black/White wire from the LED tube is power.

3. Run the two wires from the tube assembly and

connect them to the 4-pin LED/FAN input connec-
tor. Refer to the LED/FAN harness diagram given
earlier in this manual.

NOTE: If the optional fan IS NOT being used, we recom-
mend that the second LED tube be wired to this circuit.
If the optional fan is being used, we recommend that the
second LED tube be wired in parallel with the first LED tube.

SUBSONIC FILTER ADJUSTMENT
(PA1100.5 only)

This amplifier uses a subsonic filter to maximize the perfor-
mance of a subwoofer. The subsonic filter is a high-pass
filter that removes unwanted bass output at very low
frequencies form the woofer. This increases the output
of a subwoofer by as much as 3 dB by increasing the
mechanical power handling of the subwoofer. Depending
on the type of enclosure the subsonic filter can increase
the useable low frequency output by an additional 10dB!

Acceptable boost levels are determined by the type
of enclosure used, wattage of the amplifier, and the
subwoofer’s excursion capability.

The following guidelines should be used for proper set
up of the subsonic filter to provide optimum performance
and reliability from your system.

PA200.4

Power Output: 45 Watts RMS x 4 channels at 4 Ohms and

≤ 1% THD+N

Signal to Noise Ratio: -80 dBA (reference 1 Watt into 4 Ohms)
Additional Power: 50 Watts RMS x 4 channels at 2 Ohms and

≤ 1% THD+N

PA500.4

Power Output: 90 Watts RMS x 4 channels at 4 Ohms and

≤ 1% THD+N

Signal to Noise Ratio: -81 dBA (reference 1 Watt into 4 Ohms)
Additional Power: 125 Watts RMS x 4 channels at 2 Ohms and

≤ 1% THD+N

PA1100.5

Power Output: 80 Watts RMS x 4 channels at 4 Ohms and

≤ 1% THD+N

280 Watts RMS X 1 channel at 4 ohms

≤1% THD+N

Signal to Noise Ratio: -80 dBA (reference 1 Watt into 4 Ohms)
Additional Power: 125 Watts RMS x 4 channels at 2 Ohms

≤ 1% THD+N

Additional Power Subchannel: 600Watts RMS x 1 channel at 1 Ohm

≤ 1% THD+N

CEA SPECIFICATIONS
