12
Introduction
Note
• Only connect the adaptor to a switching hub (repeater hubs cannot be
used).
Master and terminal adaptors
Before using your adaptors, it is important to understand the concept of a
“master” adaptor and a “terminal” adaptor.
An HD-PLC network contains at least 2 adaptors. One (and only one)
adaptor must be configured as the master. All other adaptors are
configured as terminals. (A maximum of 15 terminals per network is
recommended.) An adaptor is configured as either a master or a terminal
during registration (see page 21). For simplicity, we recommend configuring
the adaptor that is directly connected to one of your router’s LAN ports as
the master.
