26
FEATURES AND CONTROLS
Switches
Mode/Reverse Override Switch
This vehicle is equipped with a reverse speed limiter system. To gain
additional wheel speed while backing, release the throttle and depress
the override button.
WARNING! Pressing the override button while the throttle is open can cause
loss of control, which may result in serious injury or death. Always release the
throttle before pressing the override button.
The reverse override button also acts as a MODE button when held
down for approximately one half second. The transmission cannot be in
reverse when using the override button as a MODE button.
4X4 Switch
Use the 4X4 switch to engage ADC 4X4, 4X4 or 2X4. See page 36. The
vehicle automatically engages 4X4 when operating in reverse if the
switch is set to either 4X4 position.
2x4
Mode/Reverse
Override
Button
Main Key
Switch
Engine
Stop Switch
Headlight
Switch
4X4 Switch
