Operating instructions (cont.) – Planar PL1520M User Manual
Page 17
14
OPERATING INSTRUCTIONS (cont.)
MENU SELECTION
Main Menu
Item
Main Menu
Icon
Description Note
Video
Picture set up for
composite video & s-video
mode.
Inactive when VGA
source is selected.
Sound
Sound set up for all modes.
VGA
Picture set up for PC mode
Inactive when
Video/S-Video source
is selected
Source
Source select between
VGA/Video/S-Video
OSD
OSD (On screen Display)
Set up
