Installation instructions, Power source – Planar PL1520M User Manual
Page 10
7
INSTALLATION INSTRUCTIONS
INSTALLING AND REMOVING THE BASE:
Install
Remove
Figure 1 Installing and Removing the Base
Power Source:
1. Make sure that the power cord is the correct type required in your area.
2. This LCD monitor has an Internal universal power supply that allows
operation in either 100/120V AC or 220/240V AC voltage area (No user
adjustment is required.)
3. Connect the AC-power cord one end to your LCD monitor’s AC-input
socket , the other end to wall-outlet .
