Pioneer XDJ-AERO - Manual (Page 30)

2 Effects
SW Name
MIDI message (this unit to computer)
Remarks (dd values)
When SHIFT button is off When SHIFT button is on
BEAT control
Deck A B4 0 dd B4 16 dd
Difference count value from when previously
operated
! Turn clockwise: 1 – (max) 30
! Turn counterclockwise: 127 – (min) 98
Deck B B5 0 dd B5 16 dd
Difference count value from when previously
operated
! Turn clockwise: 1 – (max) 30
! Turn counterclockwise: 127 – (min) 98
Deck C B4 8 dd B4 24 dd
Difference count value from when previously
operated
! Turn clockwise: 1 – (max) 30
! Turn counterclockwise: 127 – (min) 98
Deck D B5 8 dd B5 24 dd
Difference count value from when previously
operated
! Turn clockwise: 1 – (max) 30
! Turn counterclockwise: 127 – (min) 98
FX SELECT button
(TRANS)
Deck A 94 70 dd 94 98 dd OFF=0, ON=127
Deck B 95 70 dd 95 98 dd OFF=0, ON=127
Deck C 94 74 dd 94 102 dd OFF=0, ON=127
Deck D 95 74 dd 95 102 dd OFF=0, ON=127
FX SELECT button
(FLANGER)
Deck A 94 71 dd 94 99 dd OFF=0, ON=127
Deck B 95 71 dd 95 99 dd OFF=0, ON=127
Deck C 94 75 dd 94 103 dd OFF=0, ON=127
Deck D 95 75 dd 95 103 dd OFF=0, ON=127
FX SELECT button
(ECHO)
Deck A 94 72 dd 94 100 dd OFF=0, ON=127
Deck B 95 72 dd 95 100 dd OFF=0, ON=127
Deck C 94 76 dd 94 104 dd OFF=0, ON=127
Deck D 95 76 dd 95 104 dd OFF=0, ON=127
FX SELECT button (ROLL)
Deck A 94 73 dd 94 101 dd OFF=0, ON=127
Deck B 95 73 dd 95 101 dd OFF=0, ON=127
Deck C 94 77 dd 94 105 dd OFF=0, ON=127
Deck D 95 77 dd 95 105 dd OFF=0, ON=127
LEVEL/DEPTH
Deck A
B4
B4 2
34 MSB
LSB B4
B4 18
50 MSB
LSB
0–16383
When turned fully counterclockwise: 0 / When
turned fully clockwise: 16383
Deck B
B5
B5 2
34 MSB
LSB B5
B5 18
50 MSB
LSB
0–16383
When turned fully counterclockwise: 0 / When
turned fully clockwise: 16383
Deck C
B4
B4 10
42 MSB
LSB B4
B4 26
58 MSB
LSB
0–16383
When turned fully counterclockwise: 0 / When
turned fully clockwise: 16383
Deck D
B5
B5 10
42 MSB
LSB B5
B5 26
58 MSB
LSB
0–16383
When turned fully counterclockwise: 0 / When
turned fully clockwise: 16383
Indicator name
MIDI message (computer to this unit)
Remarks (dd values)
When SHIFT button is off When SHIFT button is on
FX SELECT (TRANS)
Deck A 94 70 dd 94 98 dd Off = 0, lit = 127
Deck B 95 70 dd 95 98 dd Off = 0, lit = 127
Deck C 94 74 dd 94 102 dd Off = 0, lit = 127
Deck D 95 74 dd 95 102 dd Off = 0, lit = 127
FX SELECT (FLANGER)
Deck A 94 71 dd 94 99 dd Off = 0, lit = 127
Deck B 95 71 dd 95 99 dd Off = 0, lit = 127
Deck C 94 75 dd 94 103 dd Off = 0, lit = 127
Deck D 95 75 dd 95 103 dd Off = 0, lit = 127
FX SELECT (ECHO)
Deck A 94 72 dd 94 100 dd Off = 0, lit = 127
Deck B 95 72 dd 95 100 dd Off = 0, lit = 127
Deck C 94 76 dd 94 104 dd Off = 0, lit = 127
Deck D 95 76 dd 95 104 dd Off = 0, lit = 127
FX SELECT (ROLL)
Deck A 94 73 dd 94 101 dd Off = 0, lit = 127
Deck B 95 73 dd 95 101 dd Off = 0, lit = 127
Deck C 94 77 dd 94 105 dd Off = 0, lit = 127
Deck D 95 77 dd 95 105 dd Off = 0, lit = 127
30 En
