29 En
List of MIDI Messages
Of the 3 bytes in MIDI messages, the first and second bytes are expressed in decimal, the third byte in hexadecimal.
MIDI channel MIDI ch. Value
Deck A 1 n=0
Deck B 2 n=1
Deck C 3 n=2
Deck D 4 n=3
Effect A/C 5 n=4
Effect B/D 6 n=5
Mixer 7 n=6
1 Player
SW Name
MIDI message (this unit to computer)
Remarks (dd values)
When SHIFT button is off When SHIFT button is on
Rotary selector (turn) Bn 64 dd Bn 65 dd
Difference count value from when previously
operated
! Turn clockwise: 1 – (max) 30
! Turn counterclockwise: 127 – (min) 98
Rotary selector (press) 9n 66 dd 9n 67 dd OFF=0, ON=127
BACK button 9n 68 dd — — — OFF=0, ON=127
TIME/AUTO CUE button 9n 62 dd 9n 63 dd OFF=0, ON=127
PLAY/PAUSE button 9n 11 dd 9n 71 dd OFF=0, ON=127
CUE button 9n 12 dd 9n 72 dd OFF=0, ON=127
AUTO BEAT LOOP control (turn) Bn 19 dd 9n 79 dd
Difference count value from when previously
operated
! Turn clockwise: 1 – (max) 30
! Turn counterclockwise: 127 – (min) 98
AUTO BEAT LOOP control (press) 9n 20 dd 9n 80 dd OFF=0, ON=127
JOG DRUM button 9n 21 dd — — — OFF=0, ON=127
SAMPLE LAUNCH button 9n 23 dd — — — OFF=0, ON=127
MASTER TEMPO button 9n 26 dd 9n 86 dd OFF=0, ON=127
TEMPO RANGE button 9n 27 dd 9n 87 dd OFF=0, ON=127
SYNC button 9n 88 dd 9n 92 dd OFF=0, ON=127
TEMPO adjustment control
Bn 0 MSB Bn 5 MSB 0–16383
0 at – side, 16383 at + side
Bn 32 LSB Bn 37 LSB
Jog dial (when outer section turned) Bn 1 dd Bn 6 dd
Difference count from previous operation
! Increases from 64 when turned clock-
wise, decreases from 64 when turned
counterclockwise.
The cumulative difference count when the
jog dial is turned 1 rotation is 1215.
Jog dial (when top section turned) Bn 2 dd Bn 7 dd
Difference count from previous operation
! Increases from 64 when turned clock-
wise, decreases from 64 when turned
counterclockwise.
The cumulative difference count when the
jog dial is turned 1 rotation is 1215.
Jog dial (when top section pressed) 9n 54 dd 9n 103 dd OFF=0, ON=127
Indicator name
MIDI message (computer to this unit)
Remarks (dd values)
When SHIFT button is off When SHIFT button is on
PLAY/PAUSE 9n 11 dd 9n 71 dd Off = 0, lit = 127
CUE 9n 12 dd 9n 72 dd Off = 0, lit = 127
AUTO BEAT LOOP LED 9n 20 dd 9n 80 dd Off = 0, lit = 127
JOG DRUM 9n 21 dd — — — Off = 0, lit = 127
SAMPLE LAUNCH 9n 23 dd — — — Off = 0, lit = 127
MASTER TEMPO 9n 26 dd 9n 86 dd Off = 0, lit = 127
SYNC 9n 88 dd 9n 92 dd Off = 0, lit = 127
MASTER LED 9n 89 dd 9n 93 dd Off = 0, lit = 127
Jog dial illumination
(4-point lighting) Blue 9n 55 dd 9n 56 dd Off = 0, lit = 127
Red 9n 57 dd 9n 58 dd Off = 0, lit = 127
List
of
MIDI
Messages
