52

FAN ERROR 5

LAMP4 FAN

Normal fan operation

51

FAN ERROR 4

LAMP3 FAN

50

FAN ERROR 3

LAMP2 FAN

49

FAN ERROR 2

LAMP1 FAN

48

FAN ERROR 1

P-UNIT FAN

47

46

45

44

43

42

41

40

39

38

37

CHANGE INTERNAL CLOCK BATTERY

Date/time is invalid (before Jan. 1, 2006 or Jan. 1, 2036 or later).

Date/time reset (after battery change)

36

FILTER CLOGGED ERROR

35

AIR VOLUME SENSOR NOT FOUND

The air volume sensor is not found.

Main power on

34

OUTPUT AIR SENSOR NOT FOUND

The output air sensor is not found.

33

DMD SENSOR NOT FOUND

The DMD sensor is not found.

32

INPUT AIR SENSOR NOT FOUND

The input air sensor is not found.

29

LAMP COVER NOT CLOSED

The lamp cover is not closed (for more than 1 second continuously).

Lamp cover closed, then main power on

28

AC VOLTAGE DROP WARNING (BELOW 90 V)

27

LAMP 4 NOT MOUNTED

The lamp is not mounted.

Lamp mounted, then main power on

26

LAMP 3 NOT MOUNTED

25

LAMP 2 NOT MOUNTED

24

LAMP 1 NOT MOUNTED

23

LAMP 4 IGNITIONFAILURE

The lamp fails to ignite.

Lamp illumination processing performed

22

LAMP 3 IGNITIONFAILURE

21

LAMP 2 IGNITIONFAILURE

20

LAMP 1 IGNITIONFAILURE

19

LAMP 4 ILLUMINATION FAILURE

The lamp fails to illuminate.

18

LAMP 3 ILLUMINATION FAILURE

17

LAMP 2 ILLUMINATION FAILURE

16

LAMP 1 ILLUMINATION FAILURE

15

LAMP 4 USAGE TIME ELAPSED

The lamp usage time exceeds the stipulated value

Lamp replaced

14

LAMP 3 USAGE TIME ELAPSED

13

LAMP 2 USAGE TIME ELAPSED

12

LAMP 1 USAGE TIME ELAPSED

11

LAMP 4 USAGE TIME WARNING

The lamp usage time exceeds the stipulated value.

10

LAMP 3 USAGE TIME WARNING

9

LAMP 2 USAGE TIME WARNING

8

LAMP 1 USAGE TIME WARNING

7

DMD LOW TEMP. ERROR

The DMD ambient temperature is lower than the stipulated value.

DMD ambient temperature at or above stipulated value

6

OUTPUT AIR TEMP. ERROR

The output air temperature exceeds the stipulated value.

Output air temperature below stipulated value

5

DMD TEMP. ERROR

The DMD ambient temperature exceeds the stipulated value.

DMD ambient temperature below stipulated value

4

INPUT AIR ERROR

The input air temperature exceeds the stipulated value.

Input air temperature below stipulated value

3

DMD LOW TEMP. WARNING

The DMD ambient temperature is lower than the stipulated value.

DMD ambient temperature at or above stipulated value

2

OUTPUT AIR TEMP. WARNING

The output air temperature exceeds the stipulated value.

Output air temperature below stipulated value

1

DMD TEMP. WARNING

The DMD ambient temperature exceeds the stipulated value.

DMD ambient temperature below stipulated value

0

INPUT AIR TEMP. WARNING

The input air temperature exceeds the stipulated value.

Input air temperature below stipulated value

Note

* Make sure to specify option FEh for this unit.

11
