11
Fig. 9 Fig. 8
B
A
A
To change grips, remove the phillips head screw (B) Fig. 8 from right side of
the handle by turning it counterclockwise. Lift the grip insert (A) from the
back of the handle. Install a new grip by first inserting the tab (A) Fig. 8 at the
top of the grip into the corresponding slot in the drill/driver handle. Hold the
grip against the handle and insert and tighten the phillips head screw (B) Fig.
8 until snug. Do not over tighten.
B
OPERATION
IT’S
A DRILL!
Fig. 10
HOW TO HOLD THE DRILL/ DRIVER AND HAMMER DRILL
The front end of the Drill/Driver may be made live if the tool drills
into live wiring in the wall. TO PREVENT ACCIDENTAL
ELECTRICAL SHOCK, HOLD THE DRILL/DRIVER AS SHOWN
IN FIG. 10, AND THE HAMMER DRILL AS SHOWN IN FIG.11.
IT’S
A HAMMER
DRILL!
Fig. 11
