-2-
CONNECTION
AC Inlet
AC Cord
DC Cord
DC Plug
12V DC Input Connector
(DC Input Terminal)
Cord Clamp
AW-RP301
Control Panel
q Plug the supplied AC cable into the AC Inlet.
w Insert the DC plug into the DC 12V IN
Connector of the control panel.
e Fasten the DC cord with the cord clamp on the
control panel to prevent the DC plug from dis-
connecting.
r Insert the AC cable plug into an AC outlet.
t Pull out the AC cable from the outlet before
switching power off.
