Usb1500, Wireless pc lan adapter – ParkerVision USB1500 User Manual

Page 14

USB1500

Wireless PC LAN Adapter

The USB port does not support “hot swapping”. Removing the ParkerVision

Wireless LAN Adapter from the USB port when power to your computer is on

may cause the software to lock. You should always disable the ParkerVision

Wireless LAN Adapter prior to removal to allow Windows to log off from the

network server.

LED

COLOR

STATUS

DESCRIPTION

POWER

Green

The ParkerVision Wireless LAN Adapter is receiving power.

LINK

Orange

The ParkerVision Wireless LAN Adapter has a successful wireless

connection.

Blinking

The ParkerVision Wireless LAN Adapter is sending/receiving data

through the wireless connection.

Windows will

automatically detect the HZ1500USB Wireless USB LAN Adapter and the FOUND

NEW HARDWARE Wizard Dialog Box will appear. Follow the on-screen instructions to install the

ParkerVision Wireless driver. If the Wireless LAN Adapter is not inserted properly, the following error

message will appear:

To conﬁ rm proper installation of the ParkerVision-Wireless LAN Adapter:

• Right-Click

MY COMPUTER from the Windows desktop.

• Click

PROPERTIES

• Open

DEVICE MANAGER

• Select the

HARDWARE folder tab, and then click the DEVICE MANAGER button.

• Double-click

NETWORK ADAPTERS. No special markers should appear next to the HZ1500USB

Wireless LAN Adapter selection.

• Double-click HZ1500USB Wireless LAN Adapter. Refer to the tab labeled

GENERAL. The DEVICE

STATUS Window will indicate that the device is working properly.

For Windows 2000 users, a DIGITAL SIGNATURE NOT FOUND

message may appear. Simply select YES to proceed.

For Windows XP users, a WINDOWS LOGO TESTING NOT FOUND dialog box may appear. Click

CONTINUE ANYWAY to proceed. ParkerVision Wireless D2D software has been tested to work

with Windows XP, and the installation should be continued with conﬁ dence.
