Pc fax – Panasonic KX-FM255 User Manual
Page 87
87
PC Fax
M
u
lt
i-
F
u
n
c
tio
n
C
e
n
te
r/
P
C
Sending documents from Windows 3.1/3.11
For example, to send documents created from Microsoft Word, proceed as follows.
1
Open the document you wish to send.
2
Select Print from the File menu.
3
Select the Setup button.
¡
The Setup dialog box will appear.
4
Select Panasonic MFC Fax from the Specific
Printer field and then select Options.
¡
The Panasonic MFC Fax dialog box will appear.
5
Set the Page Size, Resolution and Orientation.
Then click the OK button.
6
Click the OK button in the Print Setup dialog box.
7
Click the OK button in the Print dialog box.
¡
The Fax Send dialog box will appear.
8
Enter the name and fax number from the keyboard
or select the desired entry in the address book
currently displayed in the Address Book name box.
9
Select the Start button in the Fax Send dialog box.
Note:
¡
If the line is busy or there is no answer, the Message
Center Outbox application will automatically redial the
number up to 5 times.
¡
To cancel transmission after dialing:
Press
(STOP)
on the facsimile unit.
OR
Select the Outbox window in the Message Center
window, and then select the CANCEL button on the
toolbar.
