POWER xPERT 000/000/000 ACCESSORIES
Part Number List Price
Digital I/O Card: 8 Digital Input, 2 Solid-State Output, 3 Relay Output PXIO-B $629
Communications Expansion Card: ethernet 100FX, 10/100T, RS-485, RS-232 PXCE-B $1,154
Graphic Display Module PXD-MMG $1,679
Panel mounting bracket assembly for back-to-back meter to graphic display mounting PX-PMBA $209
Panel mounting bracket assembly for retrofitting a graphic display to an IQ Analyzer cutout PX-PMBB $157
Panel mounting bracket assembly for reduced graphic display rear clearance PX-PMBC $157
1GB Compact Flash Card PX-1GBCF $524
Power Xpert 4000/6000/8000 Meter Catalog Numbering System
Px 0 A B B
Example 1: PX8251A5BB (PX 8000 Meter, w/ VAUX, Std pwr, 512MB CF, Com. Exp. & I/O Cards)
Example 2: PX6251A6BA (PX 6000 Meter, w/ VAUX, Std pwr, 1GB CF, Com. Exp. Card)
POWER xPERT 000/000/000 METERS
Power Quality Metering Products (continued)
Model Series
4 = 4000 (Standard Power Quality)
6 = 6000 (Enhanced Power Quality)
8 = 8000 (Premium PQ w/ Transient Capture)
Voltage Input Configuration
0 = Standard (V
1
, V
2
, V
3
, V
4
)
2 = Standard plus auxiliary (V
6
, V
7
, V
8
)
Power Supply Configuration
1 = Standard 100-240 VAC or 110-250
VDC Power Supply
4 = 24-48 VDC Option (future option)
Card Slot 3 Configuration
A = No Card Option
B = I/O Option Card(8 Digital Inputs, 2 Solid
State Outputs, 3 Relay Outputs)
Card Slot 2 Configuration
A = No Card Option
B = Communication Expansion Card w/
10/100Base T, 100F, RS-485, RS-232 Ports
Card Slot 1 Configuration
5 = Standard Communications Main
Board w/ 512MB CompactFlash Card
6 = Standard Communications Main
Board w/ 1GB CompactFlash Card
