SOFTWARE AND CONNECTIVITY OPTIONS
Bundled with Software Suite CD and communication cable. See the software and connectivity product section for more detail.
UNIVERSAL MODULE ASY-0 RUNTIME CHART IN MINUTES (FULL LOAD/HALF LOAD)
Load (VA) Number of strings (2 battery modules per string; 2 battery modules occupy 1-slot)
1 String 2 String 3 String 4 String 5 String 6 String 7 String 8 String 9 String 10 String 11 String 12 String
3 kVA 8/24 24/59 43/95 58/140 80/175 95/125 119/240 135/290 155/335 165/365 200/395 215/450
6 kVA 8/24 16/40 24/59 32/83 40/103 49/114 58/140 69/156 83/175 90/190 103/205
9 kVA 8/24 13/35 18/46 24/59 29/63 35/86 40/103 46/115 54/125 58/140
12 kVA 8/24 13/33 16/40 19.5/43.5 24/59 29/70 33/80 36/90 41/100
15 kVA 8/24 11.5/31 14.5/31.5 18/46 20.5/51 24/58 28/66 31/73
18 kVA 8/24 11/31.5 13/36 15.5/41 18/45 20.5/51 24/58
Additional battery runtimes available up to 8 hours. Please contact your Powerware representative.
13 String 14 String 15 String 16 String 17 String 18 String 19 String 20 String 21 String 22 String 23 String 24 String
3 kVA 225/500 245/540 270/600 290/620 315/650 335/690 350/720 365/780 375/850 395/890 425/920 450/950
6 kVA 113/335 123/255 135/273 143/290 148/315 156/333 165/350 175/365 183/385 190/395 198/420 205/440
9 kVA 63/150 73/165 80/178 86/190 93/200 100/210 107/225 115/240 121/255 125/270 135/280 143/290
12 kVA 47/110 52/121 56/130 58/140 65/147 70/156 75/165 80/175 85/185 90/195 95/205 100/215
15 kVA 34/83 38/94 41.5/103 44.5/113 46.5/117 51/127 56/130 58/140 61/149 66/158 71/165 73/170
18 kVA 27/65 31.5/72 34.5/77 36/83 38/94 41/100 44/105 45/115 48/122 54/131 57/137 58/140
Battery strings above and to the right of the dark line require additional (N+X) power modules or a 20A charger module.
SPLIT-PHASE MODULE ASY-0 RUNTIME CHART IN MINUTES (FULL LOAD/HALF LOAD)
Load (VA) Number of Strings (2 battery modules per string; 2 battery modules occupy 1-slot)
1 String 2 String 3 String 4 String 5 String 6 String 7 String 8 String 9 String 10 String 11 String 12 String
3 kVA 6.5/16 16/40 27.5/67.5 40/98 53.5/132 67.5/167 83/204 98/242 115/283 132/324 149/365 167/408
6 kVA 6.5/16 11/27.5 16/40 21.5/53.5 27.5/68 33.5/83 40/98 46.5/115 53.5/132 60.5/149 67.5/167
9 kVA 6.5/16 9.5/23.5 13/31.5 16/40 20/49 23.5/58 27.5/67.5 31.5/78 35.5/88 40/98
12 kVA 6.5/16 9/21.5 11/27.5 13.5/33.5 16/40 19/46.5 21.5/53.5 24.5/60.5 27.5/68
15 kVA 6.5/16 8/20.5 10/25 12/30 14/35 16/40 18.5/45 20.5/50.5
18 kVA 6.5/16 8/20 9.5/23.5 11/27.5 12.5/30 14.5/35.5 16/40
Additional battery runtimes available up to 8 hr. Please contact your Powerware representative. Split-phase Module is for U.S. use.
13 String 14 String 15 String 16 String 17 String 18 String 19 String 20 String 21 String 22 String 23 String 24 String
3 kVA 185/456 204/501 223/549 242/595 262/640 283/692 302/750 323/790 345/850 365/900 387/955 408/1015
6 kVA 75/185 83/204 90/223 98/242 106/262 115/285 123/302 132/324 140/345 149/365 157/388 167/408
9 kVA 44/109 49/120 53.5/132 58/143 63/154 68/167 73/179 78/191 83/204 88/210 93/229 98/242
12 kVA 30.5/75 33.5/83 37/90 40/98 43/106 46.5/115 50/123 53.5/132 57/140 60/149 64/157 68/167
15 kVA 23/56 25/62 27.5/67.5 30/73.5 32.5/79.5 35/86 37.5/92 40/98 42.5/105 45/111 48/118 51/124
18 kVA 18/44 20/49 21.5/53.5 23.5/58 25.5/63 27.5/68 29.5/73 31.5/78 33.5/83 35.5/88 38/93 40/98
Battery strings above and to the right of the dark line require additional (N+X) power modules or a 20A charger module.
CUSTOMIZABLE INPUT PLUG OPTIONS 1
Input Plug Power Module Type CTO Digit List Price
L6-30P 2 Universal C $109
L14-20P 3 Split-Phase F $109
L14-30P 2 Split-Phase G $129
14-50P 4 Split-Phase H $149
1. May be configured to order through or sales office: 800.356.5794. 2. Limits chassis to maximum current of 24A and three power modules for 5 kVA redundant. 3. Limits chassis to maximum current of
16A and two power modules for 3 kVA redundant. 4. Limits chassis to maximum current of 40A and four power modules for 8 kVA redundant.
