Three-phase Online (0– kVA)
This new product combines advanced technology with uncompromised efficiency, superior reliability, and installation flexibility.
Today's datacenters, communications and network control centers, as well as process control applications will benefit from
increased uptime when incorporating this advanced UPS into their power chain. Each Powerware 9355 system incorporates the
features below and is supported by Eaton's unparalleled service, all at an affordable price in a single cabinet!
• Online, double-conversion topology
• Compact footprint (12" wide by 33" deep) for UPS and standard battery
• Plug-connected outputs optional
• Low input THD, high efficiency
• Built in maintenance bypass
• Ensures data and system integrity with a complete power management software package
for remote monitoring, management, and shutdown over the network and the intranet.
THREE-PHASE SERIES 9
Powerware 9355
POWERWARE 9 (0– kVA)
Input/Output Base Dimensions Weight List
Model 2 Part Number 1 Power Rating Voltage Runtime (H x W x D, inches) 3 (lb) 3 Price
PW9355 10 kVA with 32-Battery (2-high) KA1011100000010 10 kVA (9kW) 208/208 8 32.2 x 12.0 x 33.7 373.0 $13,800
PW9355 10 kVA with 64-Battery (3-high KA1012100000010 10 kVA (9kW) 208/208 22 47.8 x 12.0 x 33.7 609.0 $15,440
PW9355 10 kVA with 32-Battery (2-high) KA1011200000010 10 kVA (9kW) 220/220 2 8 32.2 x 12.0 x 33.7 373.0 $13,800
PW9355 10 kVA with 64-Battery (3-high) KA1012200000010 10 kVA (9kW) 220/220 2 22 47.8 x 12.0 x 33.7 609.0 $15,440
PW9355 10 kVA with 32-Battery and input KA1013400000010 10 kVA (9kW) 480/208 8 47.8 x 12.0 x 33.7 577.0 $17,770
isolation transformer (3-high)
PW9355 10 kVA with 32-Battery and input KA1013600000010 10 kVA (9kW) 600/208 8 47.8 x 12.0 x 33.7 577.0 $17,770
isolation transformer (3-high)
PW9355 15 kVA with 32-Battery (2-high) KA1511100000010 15 kVA (13.5kW) 208/208 4 32.2 x 12.0 x 33.7 373.0 $15,500
PW9355 15 kVA with 64-Battery (3-high) KA1512100000010 15 kVA (13.5kW) 208/208 13 47.8 x 12.0 x 33.7 609.0 $17,230
PW9355 15 kVA with 32-Battery (2-high) KA1511200000010 15 kVA (13.5kW) 220/220 2 4 32.2 x 12.0 x 33.7 373.0 $15,500
PW9355 15 kVA with 64-Battery (3-high) KA1512200000010 15 kVA (13.5kW) 220/220 2 13 47.8 x 12.0 x 33.7 609.0 $17,230
PW9355 15 kVA with 32-Battery and input KA1513400000010 15 kVA (13.5kW) 480/208 4 47.8 x 12.0 x 33.7 577.0 $19,350
isolation transformer (3-high)
PW9355 15 kVA with 32-Battery and input KA1513600000010 15 kVA (13.5kW) 600/208 4 47.8 x 12.0 x 33.7 577.0 $19,350
isolation transformer (3-high)
1. 50/60 Hz auto-serving.
2. 220V units are wye connected 220/127V input and 220/127V output, 3-phase, 4-wire plus ground.
3. Add 47 lbs for 2-high confifurations or 50 lbs for 3-igh configurations to determine shipping weight.
4. An input neutral is required for all configurations unless the input isolation transformer is used.
5. For parallel systems, change CTO digit #5 to a “2” and add $300 to the list price and include Parallel ie Cabinet.
POWERWARE 9 OPTIONS
Part Power Input/Output Dimensions Weight List
Model Number Rating Voltage (H x W x D, inches) (lb) Price
PW9355 10-15 kVA 2-High Line & Match Extended Battery Module 103004192-5501 64 Batteries NA 32.2" x 12" x 30.2" 480 $4,425
PW9355 10-15 kVA 3-High Line & Match Extended Battery Module 103004193-5501 96 Batteries NA 47.8" x 12" x 30.2" 710 $6,315
PW9355 Wall Mount Parallel Tie Cabinet, 2-Breaker MBP 124100020-001 NA 208V/208V 36" x 20" x 5.75" 66 $1,599
(225A Bus, 200A Neutral, 1 225A MBP, & 4 80A MIS)
PW9355 Remote EPO Switch
103002939 Wall-Mounted $279
PW9355 10-15 kVA Seismic Mounting Kit 103004194-5501 Zone 4 Kit $1,799
Remote Monitor Panel See Page 61
CAN Bridge Parallel Card 103004336
PW9355 Spare Parts Kit See Service Section
Upgrade 9355 10 kVA to 9355 15 kVA See Service Section
Upgrade a standard UPS to a parallel UPS module See Service Section
