Planar VS15XAD User Manual
Page 17
Operations Manual (OM705-00)
13
Basic Menu
Figure 7. Basic Menu
Basic Setting Menu
•
CONTRAST
Adjust the contrast level of the display.
BRIGHTNESS
Adjust the brightness of the display’s backlight.
VOLUME
Adjust the audio volume.
DDC
Digital/Analog DDC mode (information only).
Position Menu
Figure 8. Position Menu
Position Menu
AUTO ADJUST
Automatically adjust the picture quality and alignment. It is
recommended that you use this function in Microsoft™
Windows™ or similar environments. This function is not
available in the interlaced modes of operation.
PHASE
Adjust the screen display for focus and clarity.
CLOCK
Adjust the display pixel alignment.
H-POSITION
Adjust the display position horizontally.
V-POSITION
Adjust the display position vertically.
GRAPH/TEXT
Select Graph or Text expansion method while 640 x 400 or
720 x 400 mode. (Not available in all modes.)
RESET
Reset all the parameters in this menu.
