Operations Manual (OM705-00) 7
Identifying Components
Front View
Figure 1: Controls and Front View
1. Monitor Screen
The screen is capable of producing most display standards from 640 x 480
VGA to 1024 x 768 XGA.
2. Function Buttons
Press the button to access the OSD Main Menu.
Press the button to navigate through the different OSD menus
When the OSD menu is displayed, press these buttons to select a control
function.
3. Adjustment Buttons
Use the button to increase the selected setting. Use the button to decrease
the selected setting.
4. Power Switch/On-Screen Display
Depress this button for two seconds to turn monitor on/off.
5. Power-On Indicator
The Power LED is illuminated when monitor is on and blinks when the
monitor is in power-saving mode.
6. Stereo Speakers
Built-in amplifier and stereo speakers for sound. Connect the computer’s
audio-out port to the monitor’s audio-in port using the supplied audio cable.
