DIN extension cord
(supplied with CA-CD55)
CD changer input cord
L (white)
R (red)
Ground lead
Dual changer
control unit
(CA-CD55, option)
RCA cord
(supplied with CA-CD55)
Ground lead
DIN cord DIN cord
Dual changer
output cord
Fuse (3 A)
(Brown/white stripe)
Dual CD changer control lead
Changer 1
connecting
cord Changer 2
connecting
cord
R (red)
L (white)
Battery lead
RCA cord
CD
.C-IN
TWIN CD
.
C-CONT
RCA cord
Fuse (3 A) Battery lead
CD changer
(CX-DP88U, option) CD changer
(CX-DP88U, option)
Note:
≥ For details on the Sirius receiver
connections, refer to the separate
operating guide for Sirius.
Power connector 6
E
N
G
L
I
S
H
40
55
CQ-DFX683/DF583/DF203U
E
N
G
L
I
S
H
39
54
Electrical Connections
(continued)
CQ-DFX683/DF583/DF203U
❐ Upgrading the System 1
Example Combination
≥
CD changer (CX-DP88U, option)
≥ Stereo power amplifier (option)
Note:
≥
For wiring, carefully read the operating instructions for the devices connected.
CD changer
control connector
Stereo power
amplifier
(bridged
connection)
Subwoofer
DIN cord
Fuse (3 A)
Extension cord
(supplied with CX-DP88U)
CD changer (CX-DP88U, option)
Ground lead
Battery lead
Monaural
R (red)
(White)
(Red)
Subwoofer cord
CD changer input cord
CQ-DFX683U
L (white)
CQ-DF583U
S.W-OUT
CQ-DFX683U
CD.C-IN
Preamp output connector (rear)
Preamp output connector (front)
RCA cord
(option)
RCA cord (R)
RCA cord (L)
: L (white)
: R (red)
CQ-DFX683U CQ-DF583U
Example Combination
≥
CD changer (CX-DP88U, option)
≥ Dual changer control unit
(CA-CD55, option)
❐ Upgrading the System 2 CQ-DFX683U CQ-DF583U
