The Top Gun Module
102
PT2000 & Top Gun
4.
Place the flat metal plate at the top end of the elastic hand strap
over the indentation on the back of the Top Gun module and
insert the screws (refer to
).
Figure C-3: Replacing the hand strap (magnified view)
5.
Tighten the screws until the metal plate is secure.
6.
Replace the hand-strap hook into its holder.
Indentation on back
of Top Gun module
Hand strap
Flat metal plate
