PSC PT2000TM - Manual (Page 110)

The Top Gun Module
100 PT2000 & Top Gun
Attaching the Top Gun Module to the PT2000
If the Top Gun module and PT2000 were purchased separately,
complete the following steps to connect them:
1. Pull the hook on the elastic hand strap out of the holder near the
base of the PT2000 (refer to
Figure C-1 ).
Figure C-1: The back of the PT 2000
2. Remove the two screws that attach the other end of the hand strap
to the PT 2000 (refer to
Figure C-1 ).
Remove these screws after
releasing the hook
Release the strap hook here
