FORD Appendix
Aux2Car Adaptor Connection Car Car
2004 - Town Car, Grand Marquis, Marauder,
LS and Ford Crown Vic.
1. Preparing the Ford-12pin Cable
Take the PXHFD4 cable and cut off the black 12-pin plug. You will use only the cable and
big White 22 pin connector (connects to the iPod2car).
2. Connection to the Vehicle
There are two connectors located behind the radio, a 16 pin connector and a 24 pin con-
nector.
We will fi rst work with the 16 pin connector.
16pin Connector:
Red to 16pin connectors Orange/Black cable (Pin #9)
Blue to 16pin connectors Gray cable (Pin #10)
Green to 16pin connectors Light Green/Red cable (Pin #1)
Pink to 16pin connectors Violet cable (Pin #2)
Yellow to 16pin connectors Light Blue/Pink cable (Pin #7)
White to 16pin connectors Tan cable (Pin #8)
Brown to 16pin connectors Light Green/Black cable (Pin #6)
24pin Connector:
Gray to 24pin connectors Violet/Light Blue cable (Pin #1)
Orange to 24pin connectors Black/Light Green cable (Pin #24)
*Important Note:
Some vehicle production runs do not have a cable plugged into the 16pin pin connector
on the back of the headunit. If you are installing in this type of vehicle you can use another
cable (For example the Honda cable) and shave the plastic off of the white 22pin connector
and remove the pins inside. These pins can then be inserted into the holes on the back of
the vehicles stereo. Call technical support if you need further assistance with this option.
3. Technical Support
If you have any questions or need any support, please feel free to call 800-477-2267 from
9:30am-6pm EST.
