I I . S A F E T Y

PRODUCT SAFETY SYMBOLS
The symbols below are used on the power chair to identify warnings, mandatory actions, and prohibited actions. It is very
important for you to read and understand them completely.

Corrosive chemicals contained in battery. Use only AGM or Gel-Cell batteries to reduce

the risk of leakage or explosive conditions.

This product has been tested and passed at an immunity level of 20 V/m.

Read and follow the information in the owner’s manual.

Maximum seating weight.

Locked and in drive mode.

Place unit on level ground and stand behind or to one side when changing from drive

mode to freewheel mode or freewheel mode to drive mode.

Unlocked and in freewheel mode.

Battery Set Configuration:

+

++

++ = Positive (Red) Terminal Post

- = Negative (Black) Terminal Post

Connect Red wires to Red Positive (+) Terminal Posts

Connect Black wires to Black Negative (–––––) Terminal Posts
