7
VCR
TIMER
A
M Hi-Fi
Rear View of the VCR
OUT IN 1
OUT TO TV VIDEO
AUDIO IN FROM ANT.
VHF/UHF
R
L
VHF/UHF Antenna
Input Terminal
VHF/UHF Antenna
Output Terminal
Video Output
Connector
AC Power Plug
Audio Output
Connector (L/R)
Audio Input
Connector (L/R)
Video Input Connector
Hi-Fi Indicator
Lights up when Hi-Fi audio
is monitored in Playback
Mode.
VCR Indicator
Lights up when the
VCR/TV selector is
set to VCR.
Power Indicator
Lights up when power is on.
Clock/ Status/ Channel/ Speed Display
Displays the current time. Briefly displays VCR
status when a function button is pressed.
Briefly displays the channel number, or “L1” or
“L2” when a channel or line input is selected.
Briefly displays the recording speed when
SPEED is pressed.
Multi Function Display
Timer Indicator
Lights up when the VCR is set for Timer
Recording, or when One Touch Recording (OTR)
is used. Flashes when a Timer Recording is set,
but tape has not been inserted into the VCR.
Initial Setup
(Connection)
Note
• While plugged into an AC outlet, the VCR consumes 3.0 W of electrical power in off mode.
