7�2 Connect devices

This section describes how to connect

various devices with different connectors and

supplements examples provided in the Quick

Start Guide.

Caution:

Disconnect the mains cord

before connecting devices.

Note:

Different types of connectors may

be used to connect a device to your TV,

depending on availability and your needs.

Blu-ray Disc player
For full high-definition video, connect a HDMI

cable as illustrated:

DVD player
For DVD video, connect a SCART cable as

illustrated:

Satellite receiver
To receive analogue channels via antenna

and digital channels via a satellite receiver,

connect an antenna cable and SCART cable as

illustrated:

HD digital receiver
To receive analogue channels via antenna

and digital channels via a HD digital receiver,

connect two antenna cables and HDMI cable as

illustrated:

Combined DVD recorder and digital

receiver

To receive analogue channels via antenna and

record programs on a combined DVD recorder

and digital receiver, connect two antenna cables

and one SCART cable as illustrated

Separate DVD recorder and receiver
To receive analogue channels via antenna

and record programmes on a separate DVD

recorder and receiver, connect three antenna

cables and one SCART cables as illustrated:

DVD recorder and home theatre system
To receive analogue channels via antenna,

output sound to a home theatre system and

record programmes on a DVD recorder,

connect two antenna cables, one SCART cable

and two digital audio cables as illustrated:

Note:

If using a home theatre or other

audio system, the best synchronisation

between images and sound is achieved

by connecting the audio signal from your

playback device to the TV first. Subsequently,

channel the audio signal to the home

theatre system or audio device via the audio

connectors on the back of the TV.
