Panasonic AJ-HD1400P - Manual (Page 40)

40
Setup menus
(continued)
OPERATION
*1 Displayed menus may vary depending on the settings in
menu No. 25 SYSTEM FREQ. For details, refer to
“Menus which are displayed” (page 32).
“_____” indicates the factory setting.
No./Item Description of setting
100
SEARCH
ENA To set the transition method to search mode (stick
operation).
0000
STICK :
Shift to the search mode when the SEARCH button
is pressed or when the stick is operated.
0001 KEY :
Do not shift to the search mode unless the
SEARCH button is pressed.
101
SHTL MAX For setting the maximum speed in the shuttle mode.
0000
X8.4 :
8.4 k normal speed
0001 X16 :
16 k normal speed
0002 X32 :
32 k normal speed
The maximum speed for the HD SP mode is
automatically limited to 25
k normal speed.
102
FF.REW MAX For setting the maximum speed of fast forward or
rewind operations.
0000
X16 :
16 k normal speed
0001 X32 :
32 k normal speed
0002 X50 :
50 k normal speed
z The maximum speed for the HD SP mode is
automatically limited to 25 k normal speed.
z The maximum speed for the DV and DVCAM
modes is automatically limited to 32 k normal
speed.
104
REF ALARM For setting whether a warning is to be displayed when
the REF VIDEO signal is not connected.
0000
OFF :
No warning is displayed.
0001 ON :
A warning is displayed by the flashing STOP lamp.
105* 1
AUTO EE
SEL
For setting the mode of the VTR, which becomes the
EE state when menu item No. 140 OUTPUT is set to
“EE.”
0000
S/F/R :
The mode changes to the EE state when this item
is set to STOP, FF, or REW.
0001 STOP :
The mode changes to the EE state only when this
is set to STOP.
106
EJECT EE
SEL For setting the output conditions of video images and
voice when ejecting the tape.
0000
EE :
Both the video and audio signals are always output
in the EE (electric modulation to electric playback)
mode regardless of the setting of the menu No.140
OUTPUT.
0001 BLACK :
The output status differs according to the setting of
the menu No.140 OUTPUT.
EE:
The signals are output in the EE mode.
TAPE: BLACK is output for the video, and the
audio is muted.
0002 GRAY :
The output status differs according to the setting of
the menu No.140 OUTPUT.
EE:
The signals are output in the EE mode.
TAPE: GRAY is output for the video, and the audio
is muted.
When “23/24” mode, “25 (HD/SD)” mode, or “50 (HD/
SD)” mode is selected in menu No. 25 SYSTEM
FREQ, BLACK is output if “EE” is selected.
No./Item Description of setting
107* 1
EE MODE
SEL
For setting the HD SDI and HD analog component
output signals in EE mode when HD SDI input is
selected.
0000
NORMAL :
Signals delayed by the time taken by internal signal
processing are output.
0001 THRU :
Signal processing is not undertaken internally, and
the signals are output without delay at their original
timing.
z The superimposed information is not displayed
when THRU is used as the setting.
z When 1394 or SG is selected for the input signal in
edit mode, internal signal is selected forcibly
“NORMAL”.
108
PLAY DELAY For setting the play rise time in frame increments.
0000
0
: :
0015
15
109* 1
CAP. LOCK
For selecting in how many field increments the
playback framing is to be locked.
0000
2F
0001 4F
0002 8F
z “8F” can be selected only when “50i/25p” is
selected as the menu item No.25 SYSTEM FREQ
setting.
z In the HD LP or HD SP mode, 2F mode is selected
when recording and playing back, including editing,
regardless of the menu.
110
AUTO REW For setting whether the tape is to be automatically
rewound to its beginning when the tape end is detected.
0000
OFF :
The tape is not rewound.
0001 ON :
The tape is rewound to its beginning.
112
FRZ MODE
SEL For setting the video output when the mode is
transferred from playback images to standby OFF
(half loading) mode or EJECT mode.
0000
DIS :
The video output is muted.
0001 STBOFF :
When the standby OFF (half loading) mode is
established, the image played back at that moment
is frozen and output.
0002 SOF&EJ :
When in the STANDBY OFF mode and the EJECT
mode, the image played back at that moment is
frozen and output.
z The frozen status will be according to the settings
in menu No. 604 FREEZE SEL.
z In the EJECT mode, the frozen image will be
output only when setup No. 106 EJECT EE is the 1
(BLACK) or 2 (GRAY) setting.
114
REC INH
LAMP For setting the operation of the REC INHIBIT lamp when
the cassette is set to the erasure prevention status.
0000
LIGHT :
The lamp lights.
0001 FLASH :
The lamp flashes.
When the REC INHIBIT switch on the front panel is set
to ON, the REC INHIBIT lamp lights at all times
regardless of what setting is selected for this menu item.
