Product is patented in the U.S., Canada, and Mexico.

PVI INDUSTRIES, LLC

FORT WORTH, TEXAS 76111

PV 6555 02/25/04

(800) 784-8326

• www.pvi.com

LOW NO

x

TURBOPOWER

®

• PACKAGED WATER HEATER

POLYSHIELD

®

POLYMER-LINED STORAGE TANK

TANK SERIES 250 GALLONS HORIZONTAL

Recovery gph

c

Dimensions (inches)

Blower

Motor

MODEL

NUMBER

40° - 120°F 40° - 140°F

INPUT

Btu/h

Min. Inlet

Flow Gas

Pressure

" W.C.

e

SCAQMD Energy

Model No.

A B C J

d HP Amps

Shipping

Weight

lbs

250 PHE 250A-TPL

250

200

199,000

4.5

2TPL

199 MBtu/h

23

4

1/2

16

1/3

8

1395

375 PHE 250A-TPL

375

300

300,000

4.5

3TPL

299 MBtu/h

23

4

3/4

16

1/3

8

1400

500 PHE 250A-TPL

500

400

399,000

4.5

4TPL

399 MBtu/h

23

5

3/4

16

1/3

8

1400

c Recoveries based on 83% thermal efficiency. ASHRAE 90.1 compliant for efficiency and standby loss.
d “J” dimension is for the burner housing only – gas train may exceed this dimension.
e Standard gas train.
* The information presented is for natural gas 0.6 S.G.
Dimensions are in inches unless otherwise specified.
For standard and optional equipment, see form #PV6550.
















STANDARD GAS PRESSURE REQUIREMENTS:

SEE TABLE FOR MINIMUM PRESSURE BY MODEL NUMBER.

MAXIMUM STATIC INLET GAS PRESSURE IS 14" W.C.

FOR GAS PRESSURES OUTSIDE OF THIS RANGE,

CONTACT YOUR PVI REPRESENTATIVE.

VENTING REQUIREMENTS:

-.02" TO -.06" W.C. (NEGATIVE PRESSURE).

TYPE B VENTING.

ENTIRE VENT SYSTEM SHOULD NEVER BE SIZED BASED UPON

THE VENT CONNECTION DIAMETER EXCLUSIVELY. CHECK

NATIONAL FUEL GAS CODE UNDER "FAN ASSISTED."

STANDARD ELECTRICAL REQUIREMENTS:

CONTROL VOLTAGE: 120V, 1Ø, 60 HZ., 2 AMPS.
MOTOR VOLTAGE: 1/3 HP ARE 120V, 1Ø, 60 HZ.

208V, 230V AND 460V MOTORS ARE AVAILABLE BUT WILL
REQUIRE A SEPARATE 120V/2 amps CONTROL CIRCUIT OR AN
OPTIONAL CONTROL CIRCUIT TRANSFORMER.

PVI RESERVES THE RIGHT TO CHANGE THE DESIGN AND

SPECIFICATION WITHOUT NOTICE.
