((2 24 4)) S SP PE EA AK KE ER R O OU UT TP PU UT TS S
These paralleled 1/4" mono (TS) jacks are provided for the connection of speaker enclosure(s).
Minimum speaker impedance is 4 Ohms. The CABINET IMPEDANCE switch (25) must be set to
match the load of the speaker cabinet(s).
((2 25 5)) C CA AB BIIN NE ET T IIM MP PE ED DA AN NC CE E
This three-position switch allows for appropriate selection of speaker cabinet impedance. If two
enclosures of equal impedance are used, the switch should be set to half the individual value. For
example, two 16 Ohm enclosures necessitate an 8 Ohm setting, while two 8 Ohm enclosures
would require a 4 Ohm setting. Minimum speaker impedance is 4 Ohms.
((2 26 6)) G GR RO OU UN ND D P PO OLLA AR RIIT TY Y S SW WIIT TC CH H
This three-position rocker switch should normally be placed in the center (0) position. If hum or
noise is noticed coming from the speaker enclosure(s), the switch may be placed in the “+” or “-”
position to minimize hum and noise. If changing the polarity does not alleviate the problem,
consult your authorized Peavey dealer, the Peavey factory, or a qualified service technician.
((2 27 7)) IIE EC C M MA AIIN NS S C CO ON NN NE EC CT TO OR R
This is a standard IEC power connector. An AC mains cord having the appropriate AC plug and
ratings for the intended operating voltage is included in the carton. The mains cord should be
connected to the amplifier before connecting to a suitable AC outlet.
