Engine idles own but will not stay at low idle, Troubleshooting and repair, Caution – Lincoln Electric OUTBACK SVM204-A User Manual

Page 47

OUTPUT PROBLEMS

Observe Safety Guidelines detailed in the beginning of this manual.

PROBLEMS

(SYMPTOMS)

POSSIBLE AREAS OF

MISADJUSTMENT(S)

RECOMMENDED

COURSE OF ACTION

If for any reason you do not understand the test procedures or are unable to perform the tests/repairs safely,
contact the Lincoln Electric Service Department for technical troubleshooting assistance before you proceed.
Call 1-888-935-3877.

CAUTION

Engine will not idle down. Weld
and auxiliary outputs are normal.

1. Check that the engine switch is

in the “Auto” position.

2. Check that the engine choke is

fully open.

3. There may be a load on the

weld or auxiliary output.
Disconnect all cables and cords.

1. The idle solenoid may be

improperly adjusted. Perform
the Engine RPM adjustment
procedure.

2. With the engine running, place

the engine switch in the “Auto”
position. Check for battery
voltage at the idle solenoid,
lead 213B. if battery voltage is
not present, check engine
switch, connector P4/J4, and
leads 213A and 213B.

3. If battery voltage was detected

in step #2 above, check
connector P4/J4, leads 215
and 215A.

4. Check for AC voltage at leads

260 (J2-3) and 261 (J2-4).
With no load on either the weld
or auxiliary output, the meter
should read about 26 mV. If
the voltage is significantly
higher than this, the toroidal
current transformer may be
faulty, or improperly wired.
This may also indicate a load
on machine input or faulty
internal components drawing
current.

5. If the above readings are

normal, replace the PC board.
