22
S PECIFICATIONS
Model Number PSP500MT-230 PSP650MT-230
Power Rating VA/W 500VA/300W 650VA/390W
DIMENSIONS: mm (in.)
Unit
W x D x H 95 x 240 x 205
(3.7 x 9.5 x 8)
95 x 240 x 205
(3.7 x 9.5 x 8)
Shipping
W x D x H 171 x 332 x 293
(6.7 x 13.1 x 11.5)
171 x 332 x 293
(6.7 x 13.1 x 11.5)
WEIGHT: kg (lbs)
Unit 4.6 (10.2) 4.6 (10.2)
Shipping 5.7 (12.6) 5.7 (12.6)
INPUT AC PARAMETERS
Surge Protection 220J
Rated Input Voltage 230VAC
Voltage Range Without
Battery Operation 175VAC - 280VAC, DIP switch selectable
(see DIP switch settings on page 13)
Frequency Range 46.5 - 63.5 Hz (±0.1 Hz)
OUTPUT AC PARAMETERS
Output Receptacles
(4) IEC-320-C13 (orange)
Battery backup + surge protection
(2) IEC-320-C13 (black)
Surge protection
Voltage (Battery mode) 230VAC ±8%
Waveform (Battery mode) Stepped Sinewave
Frequency 50 Hz or 60 Hz; auto sensing
Overload Warning
(Normal & Battery modes)
>100%
Overload Shutdown >110%
BATTERY PARAMETERS
Type Valve-regulated, nonspillable, lead acid
QuantityxVoltagexRating 1x12Vx7Ah 1x12Vx9Ah
Transfer Time 4 - 6 ms typical
Backup Time: At 25°C (77°F), resistive loading, with fully charged batteries
Full Load 4 minutes 5 minutes
Half Load 17 minutes 14 minutes
Recharge Time
6 hours to 90% of rated capacity,
after full discharge into resistive load
ENVIRONMENTAL
Operating Temperature
0°C to +40°C
(+32°F to + 104°F)
Storage Temperature
-15°C to +40°C
(+5°F to +104°F)
Relative Humidity 0% to 95%, non-condensing
Operating Elevation Up to 3000m (10,000 ft.) at 30°C (86°F) without derating
Audible Noise < 40 dBA, at 1 meter
