FIGURE 18

STEP 18:

• Attach the to the KEYHOLE CLEVIS(17) to the CABLE (23) as

shown in FIGURE 18.

FIGURE 17

STEP 17:

• SECURELY assemble three 4-1/2” PULLEYS (21) to the brackets on the BENCH FRAME (7) and LOWER CROSS SUPPORT (8), us-

ing four 3/8 X 2” BOLTS (37), one 2-7/8” CABLE CLIP (27), and four 3/8” LOCK NUTS (44) as shown in FIGURE 17. (NOTE: Posi-
tion the 2-7/8” CABLE CLIP before tightening and make sure the CABLE is running over the 3/8 X 2” retaining bolt.)

• Make sure the CABLE (23) is routed around all pulleys as shown in FIGURE 17.

37 3/8 X 2”
