Top and side views of ups – Liebert 500-650 VA User Manual
Page 9
5
Top and Side Views of UPS
Refer to Bottom for
Cautionary Markings
Orange output receptacles
Battery backup + surge protection
Black output receptacles
Surge protection only
USB interface
port (for
PAXXX-230U
models only)
Data Line
Protection
Connectors
(IN, OUT, OUT)
Phone/Fax/DSL/
Internet/Modem
Devices
Circuit Protector
TOP OF UPS
LEFT SIDE OF UPS
RIGHT SIDE OF UPS
Mains/Battery Indicator
(Green)
Fault Indicator (Red)
AC Inlet
