17
S
PECIFICATIONS
Model Number
PA500-230U
PA500-230
PA650-230U
PA650-230
Model Rating VA / W 500 / 300 650 / 360
DIMENSIONS: mm (in.)
Unit
W x D x H
168 x 250 x 95
(6.6 x 9.8 x 3.7)
168 x 250 x 95
(6.6 x 9.8 x 3.7)
Shipping
W x D x H
238 x 350 x 142
(9.4 x 13.8 x 5.6)
238 x 350 x 142
(9.4 x 13.8 x 5.6)
WEIGHT: kg (lbs)
Unit 4.7 (10.4) 5.7 (12.5)
Shipping 5.7 (12.5) 6.7 (14.8)
INPUT AC PARAMETERS
Surge Protection 220J
Rated Input Voltage 230VAC
Voltage Range Without
Battery Operation
180VAC - 264VAC (±6VAC)
Frequency 47 - 63 Hz (±0.4 Hz)
OUTPUT AC PARAMETERS
Output Receptacles
(3) IEC-320-C13 (orange)
battery backup+surge protection
(2) IEC-320-C13 (black)
surge protection
Output Cord
2m (6.6 ft) detachable, w/IEC-320 (Wire Type: 1mm 2 ,
H05W-F 3G)
Voltage (Battery Mode) 230VAC (±8%)
Output Current 2.9 A 4.2 A
Waveform (Battery Mode) Stepped Sinewave
Frequency (Battery Mode) 50/60 Hz (±1 Hz)
Overload Warning >100%
Overload Shutdown >110%
BATTERY PARAMETERS
Type Valve-regulated, nonspillable, lead acid
Quantity x Voltage x Rating 1 x 12V x 5 Ah 1 x 12V x 7 Ah
Transfer Time 4 – 6 ms typical
Back-up Time:
At 25°C (77°F), resistive loading,
w/ fully charged batteries:
Full load 2 minutes 1 minute
Half load 8 minutes 8 minutes
Recharge Time
12 hours to 90% rated capacity, after full discharge
into resistive load
